Concrete Pump Piston 019004000 DN200: What to Verify

A concrete-pump delivery piston, its delivery cylinder and a hydraulic drive-cylinder component are different purchases. Before using a 019004000 / DN200 reference, establish which assembly is being repaired and what the offered part includes.
Identify the concrete-contacting component
In a piston-type concrete pump, the delivery piston moves concrete through a delivery cylinder. The hydraulic drive and concrete delivery side are related mechanisms, but their pistons, cylinders and seals are not interchangeable descriptions. Putzmeister's piston-pump overview distinguishes delivery pistons, delivery cylinders and the transfer system.
Useful photographs show the complete removed component, its attachment face and the machine assembly from which it came. Access and removal must follow the concrete pump's isolation and pressure-release procedure.
What the current listing establishes
The KuduParts listing names a piston ram, reference 019004000, with a DN200 designation. Those are the available search identifiers. The short description does not supply a complete machine-fitment matrix, material specification or dimensioned drawing.
Do not turn the DN200 label into an assumed measurement for every surface. Compare the relevant drawing or written dimensions for the installed assembly. Nor does the Putzmeister compatibility wording establish genuine Putzmeister origin.
| Comparison | Evidence to request |
|---|---|
| Machine and assembly | Concrete pump model, serial number and applicable parts-diagram reference. |
| Geometry | Working dimensions and attachment arrangement from the drawing or supplier specification. |
| Construction | The specified material/design for that application; do not infer it from colour. |
| Supply scope | One piston, an assembly or a set; any included retainers and separately required seals. |
Match the purchase to the inspection
The service provider should assess the piston and the mating delivery-cylinder condition together. Ordering a wear component is a purchasing decision after inspection, not a diagnosis from a promotional photograph. Ask which associated parts are required and which remain serviceable.
Send the full reference, machine identity, photographs and unresolved drawing questions to KuduParts. Keep unanswered dimensions visible in the enquiry rather than accepting a near match. No universal replacement interval, weight or concrete-pressure capability is implied by this article.
